The 200M Water Well Drilling Rig is intended for groundwater drilling projects requiring equipment selected according to the target depth, geological conditions and borehole specifications. Choosing the right drilling machine also involves evaluating the drilling method, power requirements and supporting equipment. As a water well drilling rig manufacturer in China, ZDrill Machinery provides drilling equipment solutions for different project requirements. Contact our team to confirm the available configuration, technical specifications and quotation for your project.
Water Well Drilling Rig Technical Parameters
| Item | Parameter | Item | Parameter |
| Usage | Water Well | Power Type | Diesel |
| The weight (T) | 2.8 | The hole diameter (mm) | 100-300 |
| Drill depth (m) | MAX.200 | Rig lifting force (T) | 12 |
| One-time advance length (m) | 2.4 | Rapid rise speed (m/min) | 20 |
| Walking speed (km/h) | 2 | Fast feeding speed (m/min) | 40 |
| Gradeability (Max.) | 30 | Width of loading (m) | 1.3 |
| Engine power (kw) | 58 | Swing torque (N.m) | 3200-4600 |
| Working air pressure (MPA) | 1.7-2.5 | Dimensions (mm) | 2600*1300*2000 |
| Air consumption (m³/min) | 17-31 | The penetration efficiency (m/h) | 10-35 |
| Swing speed (rpm) | 45-70 | The engine brand | Quanchai |
