Hydraulic Core Drilling Rig

Full Hydraulic Core Drilling Rig is a professional drilling machine widely used in geological exploration, mineral prospecting, hydrological investigation, and engineering drilling projects. The rig adopts a full hydraulic drive system with advanced wire-line coring technology, providing stable performance, accurate core sampling, and high drilling efficiency.

ZD Group will provide the design and production plan of 300-2000m core drill rigs for global mineral development experts.

CONTACT USRequest a quote
Product Details

Full Hydraulic Core Drilling Rig is a professional drilling machine widely used in geological exploration, mineral prospecting, hydrological investigation, and engineering drilling projects. The rig adopts a full hydraulic drive system with advanced wire-line coring technology, providing stable performance, accurate core sampling, and high drilling efficiency.

The rig is suitable for complex geological formations and remote working environments. It features flexible operation, compact structure, strong climbing capability, and convenient transportation. Hydraulic control improves operational safety while reducing labor intensity. Crawler-mounted or modular designs are commonly available for different project requirements.

A full hydraulic core drilling rig generally works together with drill rods, core barrels, drill bits, mud pumps, and auxiliary lifting systems. Optional configurations such as wireless remote control, automatic rod handling, and dust suppression systems can also be equipped according to site conditions and drilling applications.


ParameterSpecificationParameterSpecification
ApplicationCore Exploration Drilling RigTypeCore Drilling Rig / SPT
Drilling Depth200-2000MHole DiameterBQ/NQ/HQ/PQ/S Series /NTW/HTW/PTW
Power TypeDiesel, ElectricVoltage220V / 380V
Core ComponentsPump, EngineWarranty1 Year
Machinery Test ReportAvailableVideo Outgoing InspectionAvailable
Key Selling PointEasy Operation, MultifUnctionalPlace of OriginHebei, China
Weight5000/13000kgBrandZDrill
Dimensions (L × W × H)3900*1700*2350MMMobilityMovable
Product NameHydraulic Core Drilling RigRated Power78KW / 96KW / 154KW / 194KW (Different Models)
Max. Torque300–5000 N·m (Different Models)Engine Speed2400 / 2600 / 2800 RPM (Different Models)
Max. Pull Force6T / 8T / 12T / 15T / 20TDrilling Capacity200-2000m
Soil Sampling MethodSPT / WirelineDrilling Angle0–90°
Chassis TypeCrawler Type / Wheeled TypeApplicationGeological Exploration Drilling Operations
Prev:Core Exploration Rig
Next:No more

FAQ About Water Well Drilling Rig

  1. What types of drilling rigs do you offer?

    We supply water well drilling rigs, crawler drilling rigs, truck mounted drilling rigs, trailer drilling rigs and core drilling rigs for different drilling applications.

  2. How do I choose the right drilling rig?

    The selection depends on drilling depth, geological conditions, hole diameter and project requirements.

  3. Do you provide customized drilling equipment?

    Yes. ZDrill provides customized drilling solutions according to drilling depth, drilling method and site conditions.

  4. What industries use your drilling equipment?

    Our drilling equipment is widely used in water well construction, geological exploration, mining, geothermal projects and infrastructure development.
